GOWE USB SPDIF Balanced XLR I/O DAC Double PCM1794 Flagship Level Decoder Digital Analog Converter

Specifications Parameters: Single Dimensions: width 330mm, depth 220mm, height 70mm (excluding knob, machine feet, connector size) Frequency response: 20Hz-35KHz; SNR: general port output: 110dB; Harmonic distortion: General port output: <0.001%; Support 24bit digital stream below; Supports the following sampling frequency: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4KHz, 192KHz; Output Level: Balanced output 9V, Standard output 2V

• Specifications Parameters: Single Dimensions: width 330mm, depth 220mm, height 70mm (excluding knob, machine feet, connector size) Frequency response: 20Hz-35KHz; SNR: general port output: 110dB; Harmonic distortion: General port output: <0.001%; Support 24bit digital stream below; Supports the following sampling frequency: 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4KHz, 192KHz; Output Level: Balanced output 9V, Standard output 2V
• Dynamic Range: balanced output greater than 120dB, unbalanced output is greater than 110dB; Input impedance: 1101017 AES / 120 ohms, other digital interfaces / 75 ohms; Line Output Impedance: 600 ohms; Net Weight: 2.6Kg, ; Packing gross size weight: about 5.6Kg; Input voltage: 110v, 220v-240v 60/50Hz for all countries customer; Product Description: USB receive use TE8802L 24bit / 192K, which is a work in asynchronous or
• adaptive mode of high-end chip, 1101017 of course, this machine is the asynchronous mode, it can effectively reduce the jitter values.TE8802L is TE7022L upgraded version chip, QFP128 pin mode.USB part will directly use TE8802L's IIS out signal to link with PCM1794A decoder chip Decoder part use two PCM1794 with each for one channel on mono mode, with mono mode, PCM1794 can give a best effectif
• Use 9 Korea produced LM4562NA op-amps, Respectively for Balanced or Standard output and LPF; 5 inputs: AES balanced input, USB, RCA Coaxial, BNC Coaxial, Optical. AES use pulse transformer coupling; USB state indicator in front panel; Use US's DALE and Japan's TKD top resistors; Use all top audio capacitors; Amplification chip 1101017 use wel-know TDA1521
• Use customized 20ppm Crystal oscillator; Use all teflon sliver-plated inside single or double wires
